Arri Alexa Mini
The Arri Alexa Mini features UHD 12-bit ProRes 4:4:4:4 XQ recording internally onto CFast Cards, Open Gate ARRIRAW recording internally, and a maximum frame rate of 200 fps.
Model
Arri Alexa Mini
Sensor
35mm ALEV III CMOS with bayer pattern colour filter array
Lens Mount
PL / EF
Recording Format
ARRIRAW
ProRes 12-bit 4:4:4:4 XQ / 4:4:4:4
ProRes 10-bit 4:2:2 HQ / 4:2:2 / 4:2:2 LT
File Format
| ARRIRAW | MXF |
| ProRes | MOV |
Resolution
| ARRIRAW Open Gate | 3424×2202 |
| ARRIRAW 16:9 2.8K | 2880×1620 |
| ProRes 16:9 UHD | 3840×2160 (up-sampled from 3.2K) |
| ProRes 16:9 3.2K | 3200×1800 |
| ProRes 16:9 2K | 2048×1152 |
| ProRes 16:9 HD | 1920×1080 |
| ProRes 16:9 S16 HD | 1920×1080 (up-sampled from 1600×900) |
| ProRes 4:3 2.8K | 2880×2160 |
| ProRes 16:9 HD Anamorphic | 1920×1080 |
| ProRes 2.39:1 2K Anamorphic | 2048×858 |
Maximum Frame Rate (PAL)
| ARRIRAW 3.4K Open Gate | 30 fps |
| ARRIRAW 16:9 2.8K | 48 fps |
| ProRes 16:9 UHD 4:4:4:4 XQ | 30 fps |
| ProRes 16:9 UHD 4:4:4:4 / 4:2:2 HQ / 4:2:2 | 60 fps |
| ProRes 16:9 3.2K 4:4:4:4 XQ | 30 fps |
| ProRes 16:9 3.2K 4:4:4:4 / 4:2:2 HQ / 4:2:2 | 60 fps |
| ProRes 16:9 2K 4:4:4:4 XQ | 120 fps |
| ProRes 16:9 2K 4:4:4:4 / 4:2:2 HQ / 4:2:2 | 200 fps |
| ProRes 16:9 HD 4:4:4:4 XQ | 120 fps |
| ProRes 16:9 HD 4:4:4:4 / 4:2:2 HQ / 4:2:2 | 200 fps |
| ProRes 16:9 S16 HD 4:4:4:4 XQ | 120 fps |
| ProRes 16:9 S16 HD 4:4:4:4 / 4:2:2 HQ / 4:2:2 | 200 fps |
| ProRes 4:3 2.8K 4:4:4:4 XQ / 4:4:4:4 / 4:2:2 HQ / 4:2:2 | 50 fps |
| ProRes 16:9 HD Anamorphic 4:4:4:4 XQ / 4:4:4:4 / 4:2:2 HQ / 4:2:2 | 120 fps |
| ProRes 2.39:1 2K Anamorphic 4:4:4:4 XQ / 4:4:4:4 / 4:2:2 HQ / 4:2:2 | 120 fps |
Media
| Internal Recording | CFast 2.0 |
| Setup | USB |
Audio Recording Format
24-bit 48 kHz
Exposure Index (EI)
| EI Range | 160-3200 ASA |
| Native EI | 800 ASA |
Internal ND Filters
Clear
IRND 0.6 (2 Stops)
IRND 1.2 (4 Stops)
IRND 2.1 (7 Stops)
Batteries
V-Lock (Using V-Lock battery plate)
Inputs
1x Lemo 8-pin (Bat)
1x Lemo 5-pin (Timecode I/O)
1x Lemo 5-pin (Audio)
Outputs
2x BNC (SDI Out)
1x Lemo 16-pin (EVF)
1x Lemo 10-pin (Ethernet)
1x Lemo 7-pin (Ext)
Weight
2.3 kg (body only)
6.0 kg (with accessories*)
*Including camera body, body cap. viewfinder with cable, cage system, BP-9, aerial, 2x 15mm rods and wooden camera D-Box
