NextoDI NSB-25 Storage Bridge
The NextoDI NSB-25 allows the user to create a backup of footage from many types of memory card by using interchangeable modules. The backup can be created on up to three internal SSD’s or an external hard drive. It also features playback of 2K footage and previews of 4K footage.
Model
NSB-25
Display Size
5″
Display Resolution
800×480
Memory Card Support
| CF | Built-in CF Slot |
| SD/SDHC/SDXC | Built-in SD Slot |
| SxS | Using SxS Module |
| ASXM | Using ASXM Module |
| P2 | Using P2 Module |
| Express P2 | Using Express P2 Module |
| XQD | Using XQD Module |
| SSD | Using SSD Module |
| REDMAG | Using REDMAG Module |
| RED MINI-MAG | Using RED MINI Module |
| CFast | Using CFast Module |
| AJA PAK | Using AJA PAK Module |
Backup Storage
2x Removable Hard Drive Slots for Bridge Pellet
1x USB 3.0 Micro-B port for external hard drive
File System
| Memory Card | FAT32 / exFAT / UDF / HFS+ |
| Bridge Pellet (Internal Drive) | exFAT |
| USB External Drive | exFAT |
Video Support
| Normal Playback | H.264 / MPEG 420 / AVCHD / MPEG2 422 35M / XAVC 420 / DV |
| QUASI Playback | MPEG 422 50M / ProRes 2K |
| Preview | AVC-Intra / XAVC 422 / DNxHD / 4K Footage |
| Supported Video File Format | .mxf / .mov / .mp4 / .mts / .dv / .avi |
Video Out
1x Built-in LCD Display
1x HDMI
Audio Support
LPCM Audio
Audio Out
1x Built-in Speaker (Mono)
1x 3.5mm Mini-jack
Weight
1.5 kg
