SmallHD 703 UltraBright 7″ Onboard Monitor
Small HD 703 is the brightest 7-inch monitor available with HDR Preview, Waveform, 3D LUT support, focus and exposure tools, and 12v Lemo power.
Model
SmallHD 703 UltraBright MON-703U
Display Size
7″
Resolution
1920×1080
Inputs
1x BNC (3G/HD/SD SDI)
1x HDMI
1x 2-pin Lemo (Power)
1x Micro USB
Outputs
1x BNC (3G/HD/SD SDI)
1x HDMI
1x 3.5mm Mini-Jack (Headphones)
1x 2-pin Lemo (Power)
Supported Video Inputs
| 3G-SDI | 1920×1080 | 50/59.94/60p
50/59/94/60i |
YCC 4:2:2 10-bit |
| HD-SDI | 1920×1080 | 23.98/24/25/29/97/30p
23.98/24/25/29/97/30PsF 50/59.94/60i |
YCC 4:2:2-10-bit |
| 1280×720 | 23.98/24/25/29.97/30/50/59.94/60p
50/59.94/60i |
YCC 4:2:2 10-bit | |
| SD-SDI | 720×576 | 25i | YCC 4:2:2 10-bit |
| 640×480 | 29.97i | YCC 4:2:2 10-bit | |
| HDMI | 1920×1080 | 23.98/24/25/29.97/30/50/59.94/60p
25/29.97/30/50/59.94/60i |
RGB 4:4:4:4 8/10/12-bit |
| 1920×1080 | 23.98/24/25/29.97/30/50/59.94/60p
25/29.97/30/50/59.94/60i |
YCC 4:4:4:4 8/10/12-bit | |
| 1280×720 | 23.98/24/25/29.97/30/50/59.94/60p
100/119.88/120p |
YCC 4:2:2 8-bit | |
| 720×576 | 50/100p
25/50/100/200i |
YCC 4:2:2 8-bit | |
| 640×480 | 59.94/60/119.88/120p
23.98/24/29.97/30/59.94/60/119.88i 120/239.76/240i |
YCC 4:2:2 8-bit |
Supported Video Outputs
| 3G-SDI | 1920×1080 | 50/59.94/60p
50/59/94/60i |
YCC 4:2:2 10-bit |
| HD-SDI | 1920×1080 | 23.98/24/25/29/97/30p
23.98/24/25/29/97/30PsF 50/59.94/60i |
YCC 4:2:2-10-bit |
| 1280×720 | 23.98/24/25/29.97/30/50/59.94/60p
50/59.94/60i |
YCC 4:2:2 10-bit | |
| SD-SDI | 720×576 | 25i | YCC 4:2:2 10-bit |
| 640×480 | 29.97i | YCC 4:2:2 10-bit | |
| HDMI | 1920×1080 | 23.98/24/25/29.97/30/50/59.94/60p
25/29.97/30/50/59.94/60i |
RGB 4:4:4:4 8/10/12-bit |
| 1920×1080 | 23.98/24/25/29.97/30/50/59.94/60p
25/29.97/30/50/59.94/60i |
YCC 4:4:4:4 8/10/12-bit | |
| 1280×720 | 23.98/24/25/29.97/30/50/59.94/60p
100/119.88/120p |
YCC 4:2:2 8-bit | |
| 720×576 | 50/100p
25/50/100/200i |
YCC 4:2:2 8-bit | |
| 640×480 | 59.94/60/119.88/120p
23.98/24/29.97/30/59.94/60/119.88i 120/239.76/240i |
YCC 4:2:2 8-bit |
Weight
1kg
