Sony VENICE CineAlta Full Frame 6K Camera
The Sony Venice features a 6K Full Frame sensor that can capture 16-bit RAW, 16-bit X-OCN, XAVC and MPEG. Plus, is now Netflix approved!
Techy species coming soon….
Model
MPC-3610
Sensor
Full Frame CMOS
36.2×24.4mm – 43.5 Diagonal
Lens Mount
PL / E Mount
Recording Format
RAW SQ 16-bit (with additional AXS-R7 Recorder)
X-OCN ST 16-bit (with additional AXS-R7 Recorder)
X-OCN LT 16-bit (with additional AXS-R7 Recorder)
XAVC Class480 10-bit
XAVC Class300 10-bit
MPEG
File Format
| X-OCN | .mxf |
| XAVC | .mxf |
| MPEG | .mxf |
Resolution
| RAW SQ 17:9 4K | 4096×2160 (with additional AXS-R7 Recorder) |
| RAW SQ 16:9 3.8K | 3840×2160 (with additional AXS-R7 Recorder) |
| X-OCN ST 4:3 4K | 4096×3024 (with additional AXS-R7 Recorder) |
| X-OCN ST 17:9 4K | 4096×2160 (with additional AXS-R7 Recorder) |
| X-OCN ST 16:9 3.8K | 3840×2160 (with additional AXS-R7 Recorder) |
| X-OCN LT 4:3 4K | 4096×3024 (with additional AXS-R7 Recorder) |
| X-OCN LT 17:9 4K | 4096×2160 (with additional AXS-R7 Recorder) |
| X-OCN LT 16:9 3.8K | 3840×2160 (with additional AXS-R7 Recorder) |
| XAVC 17:9 4K Class480 | 4096×2160 |
| XAVC 17:9 4K Class300 | 4096×2160 |
| XAVC 16:9 3.8K Class480 | 3840×2160 |
| XAVC 16:9 3.8K Class300 | 3840×2160 |
| MPEG 16:9 HD | 1920×1080 |
Maximum Frame Rate (PAL)
| RAW SQ 17:9 4K | 50 fps (with additional AXS-R7 Recorder) |
| RAW SQ 16:9 3.8K | 50 fps (with additional AXS-R7 Recorder) |
| X-OCN ST 4:3 4K | 24 fps (with additional AXS-R7 Recorder) |
| X-OCN ST 17:9 4K | 50 fps (with additional AXS-R7 Recorder) |
| X-OCN ST 16:9 3.8K | 50 fps (with additional AXS-R7 Recorder) |
| X-OCN LT 4:3 4K | 24 fps (with additional AXS-R7 Recorder) |
| X-OCN LT 17:9 4K | 50 fps (with additional AXS-R7 Recorder) |
| X-OCN LT 16:9 3.8K | 50 fps (with additional AXS-R7 Recorder) |
| XAVC 17:9 4K Class480 | 25 fps |
| XAVC 17:9 4K Class300 | 50 fps |
| XAVC 16:9 3.8K Class480 | 25 fps |
| XAVC 16:9 3.8K Class300 | 50 fps |
| MPEG 16:9 HD | 25 fps / 50i |
Media
| AXS-R7 Recording (RAW/X-OCN) | AXSM |
| Internal Recording (XAVC/MPEG) | SxS |
| Setup | SD |
Audio Recording Format
LPCM 4CH 24-bit 48 kHz
ISO
| ISO Range | 125-2000 |
| Native ISO | 500 |
Internal ND Filters
Clear
IRND 0.3 (1 Stop)
IRND 0.6 (2 Stops)
IRND 0.9 (3 Stops)
IRND 1.2 (4 Stops)
IRND 1.5 (5 Stops)
IRND 1.8 (6 Stops)
IRND 2.1 (7 Stops)
IRND 2.4 (8 Stops)
Batteries
V-Lock
Inputs
1x XLR 4-pin (DC Power)
1x XLR 5-pin (Audio)
1x BNC (Timecode)
1x BNC (Genlock)
1x 8-pin (Remote)
1x 12-pin (Lens)
1x RJ-45 (Network)
1x USB
Outputs
1x Hirose 4-pin (12V Power)
2x RS 3-pin (24V Power)
4x BNC (SDI)
1x BNC (MON)
1x HDMI
1x Lemo 26-pin (Viewfinder)
1x Lemo 5-pin Female (Timecode)
1x 3.5mm Mini-jack (Headphones)
Weight
3.9 kg (body only)
7.2 kg (with accessories*)
*Including camera body, body cap, EVF bracket, EVF with cable, Arri base plate, BPA-5 bridge plate adapter, BP-9 bridge plate and dovetail plate)
